Quick Answer
P0685 means ECM/PCM Power Relay Control Circuit/Open. Confirm the full manufacturer record and the actual relay-control architecture for your VIN. It does not automatically prove a bad relay or failed engine computer. Save the complete report, establish battery and module supply condition, and test the control and switched-output paths separately before replacing parts.
What Does the P0685 Code Mean?
The P0685 code reports a fault in the designated engine-controller power-relay control circuit. The relay or power-distribution arrangement helps provide the operating supply needed by the controller and associated circuits. The exact monitored path, enable conditions, and feedback strategy vary with the vehicle.
Separate the relay’s control side from its switched-power side. A coil can be commanded while damaged contacts fail to deliver the required load. A contact supply can be present while the control path is interrupted. Those are different findings and require measurements at the correct points, not a single assumption that “the relay works.”
Some vehicles use a replaceable relay; others integrate switching or distribution into an assembly. Identify the fitted design before pulling parts or bridging terminals. The same base code does not establish a universal relay location, terminal numbering, polarity, controller pin, or replacement procedure.
Volkswagen’s January 2014 Golf/GTI reference book distinguishes P0685 control-circuit/open from low, high, and relay-sense faults. That application example supports keeping control and feedback diagnoses separate. Its monitoring values are not universal circuit-testing limits for other engines.
P0685 versus relay sense and shutdown faults
| Code | General description | Key distinction |
|---|---|---|
| P0685 | Power-relay control circuit/open | Test the specified control path and actual supply response. |
| P0686 / P0687 | Power-relay control low / high | Use the exact monitored electrical-state branch. |
| P0688 | Power-relay sense circuit | A feedback/sense path needs its own identified test points. |
| P068A | Power relay de-energized too early | A shutdown-timing result, not interchangeable with P0685. |
A controller that cannot communicate may lack power, ground, wake-up, or a working network path. Loss of scan communication alone is not proof of a failed ECM/PCM.
P0685 Symptoms and Likely Causes
Symptoms depend on whether the supply problem is current or intermittent and which circuits are affected. Save the timing of the complaint, especially cranking, warm operation, shutdown, or a fault following battery or fuse-box service.
Confirm whether the engine cranks and whether the controller communicates. Different starting faults can coexist.
An interrupted controller supply can make a road test unsafe. Arrange recovery when operation is unreliable.
Supply loss can affect module communication and inputs. Use the complete report to test a common cause before replacing several parts.
A stored event with normal operation still needs evidence-based checks. A clean stationary scan may not reproduce an intermittent connection.
Practical cause-checking order
- Battery or primary connection problem: Establish battery condition and the main supply and ground paths. Recent discharge, jump-starting, loose terminals, or charging problems can change the diagnostic conditions without proving the relay itself is defective.
- Relay socket, fuse, or distribution fault: Inspect terminal retention, corrosion, overheating, water entry, and shared feeds. An unloaded voltage does not prove that a damaged socket can carry operating current.
- Control-path interruption: An open, short, poor terminal, or missing enable condition can prevent the required relay response. Identify whether the controller switches power, ground, or another signal before testing.
- Relay contact or coil defect: A click does not prove acceptable contact output under load. An apparently similar relay may have different terminal behavior or suppression components. Use the exact specification and approved test.
- Controller or integrated-distribution issue: Consider internal failure only after external circuits, supplies, grounds, and applicable setup or service information are verified. Do not condemn a module because it is temporarily unpowered.
Do not bridge relay terminals, defeat power sequencing, or ground a controller output without an explicit approved test. A wrong jumper can damage wiring or electronics and energize circuits unexpectedly.
How Serious Is P0685, and Can You Drive?
If the engine stalls, loses power unpredictably, or will not start reliably, arrange a safe diagnosis or recovery. An intermittent supply fault can return after a temporary restart. Normal traffic is not an appropriate place to test whether the relay will remain energized.
With a steady warning and normal operation, follow the owner’s manual and seek prompt diagnosis. P0685 alone does not prove inevitable mechanical engine damage. Separate oil-pressure, overheating, smoke, leakage, and other serious symptoms from the relay code and respond to them immediately.
Stop and arrange a tow Stop safely and arrange help for stalling, unsafe power loss, smoke, electrical burning, overheating, or a no-start in an unsafe location. Do not keep replacing a fuse that opens again or operating an overheated connection.
Follow the required module shutdown and battery-isolation process before removing relays or performing resistance tests. Protect high-current terminals against accidental shorts. Keep leads away from belts and fans, and use approved probing equipment. Power-distribution and controller circuits require correct diagrams and suitable electrical training.
How to Diagnose P0685 in the Right Order
-
Save the complete fault timeline before disturbing power
Record VIN, engine, controller identity, exact P0685 wording and suffix, current/history status, and available failure records. Save all module faults before clearing codes or disconnecting the battery. Note whether the concern occurs during cranking, running, key-off, heat soak, vibration, or after recent service.
Distinguish no-crank, crank/no-start, loss of communication, and a running stall. Those observations help select the first test. Record recent battery discharge or jump-starting without assuming it explains the entire fault. Mark codes introduced during intentional isolation separately from the original evidence.
-
Map relay control, switched output, and controller feeds
Use the exact wiring and connector diagrams to identify the relay or integrated switching arrangement, control path, contact supply, output, sense circuit if fitted, fuses, splices, and ECM/PCM grounds. Confirm which circuits remain powered during starting and which follow the vehicle’s shutdown sequence.
Do not assume conventional terminal numbers, control polarity, or relay interchangeability. Check the component part number and suppression design where relevant. A solid-state or integrated circuit needs its own procedure. Identify approved measurement points before unplugging a module or attempting a loaded test.
-
Establish battery condition and module supply integrity
Test the battery by the correct OEM method and inspect primary terminals and ground connections. Measure the required ECM/PCM feeds and grounds during the state associated with the failure, including cranking when specified. A normal parked battery voltage cannot establish supply stability under load.
Use the prescribed loaded voltage-drop tests and suitable breakout equipment. Check relevant fuses and distribution connections at both sides where the procedure requires it. If the controller does not communicate, establish these essentials before deciding its electronics have failed. Avoid relying on visual cleanliness or an unloaded continuity beep.
-
Test the control side and the relay response separately
Verify the required enable and control signal using the actual switching design. Use a meter or scope as required and protect controller outputs. Confirm the expected response under the specified ignition and operating conditions. A lack of command can reflect an inhibited or missing prerequisite, not necessarily a bad relay.
Evaluate the coil or control input according to the component procedure, then test switched output under the required load. A clicking relay can still have poor contacts. A voltage at an unplugged output can disappear when the normal circuit is connected. Record both command and loaded-response evidence.
-
Locate an intermittent socket, harness, or feedback defect
Inspect terminal grip, crimps, seals, relay-box water entry, heat damage, and harness movement near brackets. Reproduce the original safe conditions while monitoring the relevant measurement. Do not disturb wiring blindly until the fault disappears; record which controlled action changes the evidence.
When a sense or feedback path is involved, test it independently of the contact output according to the diagram. Compare the signal at approved points to isolate a connection problem. If all external tests pass, check current applicable OEM guidance before authorizing an internal controller or power-distribution repair.
-
Repair the proven fault and verify start/run/shutdown behavior
Repair the failed terminal, harness, fuse supply, ground, relay, or distribution component using the correct parts and sealing methods. Resolve the cause of overheating or repeated fuse failure. Do not install an arbitrary replacement relay or a permanent bypass to keep the engine running.
Restore normal connections and protection, then repeat the prescribed starting, running, and shutdown checks. Save measured supply and control results along with the final scan report. Clear erasable faults only after evidence is preserved and repair is complete. Verify the original conditions no longer interrupt operation or set the fault.
Specifications are vehicle-specific. Use the VIN-specific relay design, control polarity, terminal assignments, loaded voltage-drop criteria, coil test, and power-sequencing requirements. No universal relay pinout, resistance, bypass method, or restart count is supplied here.
P0685 Repairs and Cost Factors
A durable P0685 repair restores the required control and supply path. A poor socket needs a proper terminal repair and the cause of heat or water damage addressed. A faulty relay needs the correct replacement design. A controller replacement requires the completed external evidence and any vehicle-specific setup plan.
Programming is not a routine repair for every relay-control code. Follow a matching current OEM instruction when software work is indicated, using approved equipment and stable supply support. An iCarsoft diagnostic scanner must not be presented as universal ECU flashing equipment.
| Possible path | US quote requirements |
|---|---|
| Power-supply diagnosis | Include battery condition, loaded feeds/grounds, control, output, and intermittent checks. |
| Relay or terminal repair | Specify the exact relay design, approved terminal parts, access, and sealing. |
| Harness or distribution repair | Identify the failed section and any water/heat damage requiring additional work. |
| Controller-related work | Require external-circuit evidence, correct part identity, setup, and verification. |
Obtain a written quote using the VIN and confirmed fault. A replaceable relay, damaged socket, intermittent harness, and integrated distribution assembly require different work. Separate diagnosis, parts, labor, taxes, setup, and the start/run/shutdown verification so the estimate describes the actual repair.
Using iCarsoft CR MAX for P0685
The official CR MAX page lists all-system diagnostics and bidirectional control. Confirm exact vehicle, ECU, data list, and any required test before purchase. A controller with missing operating power may not communicate; the scanner cannot restore that supply through a software command.
Use the complete supported module scan to identify related voltage or communication events. Compare available commanded states and reported voltage with direct measurements under the same conditions. Keep the report and electrical results together instead of treating a clean code list after battery reconnection as proof of repair.
Save evidence before choosing a repair
iCarsoft CR MAX
On a supported vehicle, the CR MAX helps preserve module fault reports and relevant supply or relay data while physical measurements establish circuit condition.
Check current CR MAX price and availabilityCheck CR MAX compatibility by VINUse a relay output test only when the specific vehicle and function are supported and the OEM procedure calls for it. A menu does not prove control-driver operation, contact current capacity, or ground integrity. Do not claim universal ECU programming or a power-relay reset that repairs an external connection.
Know the measurement boundary. Actual voltage drop, current, resistance, contact behavior, terminal tension, and heat or water damage require suitable instruments and inspection. Scan data reports supported controller information; it does not physically prove the circuit.
Verify the P0685 Repair
Confirm reliable module communication and the correct supply, control, and output behavior during the specified start/run/shutdown sequence. Repeat the original safe conditions, inspect repaired connections, and save the final electrical measurements and scan report. Document any intermittent conditions that could not be reproduced.
Follow the OEM clearing and test sequence after repair. Check current and pending faults and relevant monitor information as supported. Readiness may reset after clearing. A supported permanent emissions DTC clears through its qualifying vehicle monitor, not a forced scanner erase or battery disconnect.
A permanent P0685 can remain immediately after a successful repair. If the vehicle stores it as a permanent DTC, a scan tool or battery disconnect cannot erase it. Once current and pending faults are absent, the OBD system removes the permanent record only after the applicable monitor reruns and passes.
Related controller power and relay Code Guides
P0685 Frequently Asked Questions
Does P0685 prove the power relay is bad?
No. Battery condition, supply, ground, socket, wiring, command, and loaded output need the correct tests. The code does not select a replacement part.
Is P0685 the same as a relay shutdown-timing code?
No. P0685 concerns the control circuit/open branch. P068A concerns de-energizing too early. Confirm the complete fault and use the corresponding procedure.
Does a relay click prove it works?
No. Coil movement does not prove acceptable contact output under load. Measure command and switched response separately according to the actual design.
Can I bridge the relay to keep driving?
Do not make an improvised bypass. It can defeat sequencing, energize circuits unexpectedly, or damage electronics. Use only an explicit approved diagnostic method with suitable equipment.
Does no communication mean the PCM is dead?
No. Missing power, ground, wake-up, or network operation can prevent communication. Establish these conditions before condemning a controller.
How is the P0685 repair confirmed?
Verify the required powers and grounds, relay control and loaded output, reliable operation, and relevant code status during the original safe starting, running, and shutdown conditions.
